ropelocker S.12 winch rope

Our S.12, dyneema style, 12 strand uhmwpe rope is designed for high load applications where exceptionally low weight is required.

It has been manufactured as an excellent wire-replacement rope and is comparable with products known as Spectra, Dyneema and AmSteel which are all trade names for uhmwpe rope.

S.12 winch rope features:

• Extreme strength-to-weight ratio
• 15 x stronger than steel
• Safer than wire (low recoil)
• Hydrophobic fibre (no water absorption)
• Floats
• Low creep
• Easy to splice
• Resistant to kinking
• Maintains high strength around tight-radius bends
• Exceptional UV and chemical resistance
• Abrasion-resistant coating reduces likelihood of snagging and provides superior winch drum grip


Specification:

• Heat-set UHMwPE with polyurethane coating

Options:

• 1mm - 24mm (larger diameters available on request)
• Silver-grey colour

Available in 3 constructions:
Single strand (1 – 9 mm)
Double strand (10 – 60 mm)
Braid-on-braid (64 – 105 mm)

S.12 winch rope applications:

• Wire rope replacement
• Winch lines
• Towing
• Lifting
• Perfect rope for replacing the rope in a rope scraper system (rope manure scraper)

Specification: reduce breakload by 10% for spliced ropes

Diameter 06mm 08mm 10mm 12mm 14mm 16mm 18mm Linear break load -unspliced (kg) 3400 5280 7760 12240 14320 16960 25040
